Yellow Monopile Donut Fender Low Reaction Floating Foam Fenders Marine

Name: Yellow Monopile Donut Fender Low Reaction Floating Foam Fenders Marine
Brand: DOOWIN MARINE
Price: 1 USD

Quality Yellow Monopile Donut Fender Low Reaction Floating Foam Fenders Marine for sale

Brand Name : DOOWIN MARINE

Model Number : Donut

Certification : BV, CCS, LR, DNV

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T

Fender Diameter : 1270 ~ 4200mm

Fender Material : Closed-cell Foam with PU Skin

Fender Color : Yellow, Red, Black, Orange

Fender Application : Monopile, Coner Protection, Guiding Structures

Name : Monopile Donut Fender

Packaging Details : Pallet or Plywooden Box

Delivery Time : 2~3 weeks

Supply Ability : 10pcs/per week

Contact Now

Donut Foam Fenders are an effective solution for simple berthing dolphins, guide structures and turning structures. The buoyant Donut Fenders floats up and down a single tubular pile and freely rotates to help align or redirect ships. The internal casing has long lasting, low-friction bearings that need minimal maintenance. The foam is unsinkable and cannot burst or deflate. The Donut Fender skin is durable polyurethane reinforced with continuous nylon filaments.

Donut Foam Fenders are custom-designed for every application. They have supplementary buoyancy to present a raised contact face. The donut fender body can be additionally protected with a thicker skin or wear strips to cope with ferry beltings. Bright colors are often used to improve visibility and safety. A variety of applications include corner protection, turning structures, lead-in jetties, simple breasting dolphins and bridge protection.

Donut Foam Fenders Features:

Freely rotates around a pile
Requires minimal maintenance
Will not mark ship hulls
Rises and falls with water level
Fast and easy to install
High performance
Low hull pressures
Unsinkable & cannot burst or deflate
Low reaction
Maintains freeboard across tidal range

Yellow Monopile Donut Fender Low Reaction Floating Foam Fenders Marine

Donut Foam Fenders Performance

Donut Outer Dia (mm)	Donut Outer Dia (ft)	Pile Dia (mm)	Pile Dia (ft)	Energy Absorption (kNm)	Reaction Force (kN)	Energy Absorption (ft-kip)	Reaction Fore (kip)
1270	4.2	610	2.0	7.2	116	1.6	7.9
1450	4.8	710	2.3	9.2	131	2.1	9.0
1520	5.0	762	2.5	10.5	140	2.4	9.6
1780	5.8	914	3.0	14.1	162	3.2	11.2
1910	6.3	995	3.3	16.4	175	3.7	12.0
2030	6.7	1067	3.5	18.6	186	4.2	12.8
2210	7.3	1185	3.9	22.3	204	5.0	14.0
2290	7.5	1219	4.0	23.6	210	5.3	14.4
2490	8.2	1345	4.4	28.0	229	6.3	15.7
2540	8.3	1372	4.5	29.3	234	6.6	16.0
2790	9.2	1524	5.0	35.3	256	7.9	17.6
2970	9.8	1636	5.4	40.1	273	9.0	18.7
3050	10.0	1676	5.5	42.1	280	9.5	19.2
3300	10.8	1829	6.0	49.5	304	11.1	20.8
3450	11.3	1933	6.3	54.6	319	12.3	21.9
3530	11.6	1981	6.5	57.2	327	12.9	224
3810	12.5	2134	7.0	65.9	350	14.8	24.0
3960	13.0	2241	7.4	72.1	366	16.2	25.1
4060	13.3	2286	7.5	75.1	374	16.9	25.6
4220	13.8	2388	7.8	81.3	389	18.3	26.7

Donut Foam Fenders Application

Breasting dolphins

Corner protection

Guiding structures

Yellow Monopile Donut Fender Low Reaction Floating Foam Fenders Marine
